Short Lead Time for SAE J525 DIN2391 Carbon St37.4 E355 Alloy 4140 25crmo4 Cold Drawn High Precision Hydraulic Seamless Steel Tube
Short Description:
Our personnel are generally within the spirit of “continuous improvement and excellence”, and using the excellent top quality goods, favorable rate and superior after-sales expert services, we try to win every customer’s believe in for Short Lead Time for SAE J525 DIN2391 Carbon St37.4 E355 Alloy 4140 25crmo4 Cold Drawn High Precision Hydraulic Seamless Steel Tube, To deliver prospects with excellent equipment and providers, and frequently create new machine is our company’s organization objectives. We look forward for your cooperation.
Our personnel are generally within the spirit of “continuous improvement and excellence”, and using the excellent top quality goods, favorable rate and superior after-sales expert services, we try to win every customer’s believe in for , Item have passed by means of the national qualified certification and been well received in our main industry. Our pro engineering team will often be ready to serve you for consultation and feedback. We are able to also deliver you with cost-free samples to meet your specs. Ideal efforts will probably be produced to provide you the most beneficial service and solutions. Should really you be interested in our company and solutions, please make contact with us by sending us emails or call us straight away. To be able to know our solutions and enterprise. ar more, you’ll be able to come to our factory to see it. We will constantly welcome guests from all over the world to our firm. o build business enterprise. elations with us. Please feel absolutely free to speak to us for organization. nd we believe we are going to share the best trading practical experience with all our merchants.
At Haihui Steel, we apply our metallurgical and production expertise to manufacture high-performance seamless mechanical pipe products to meet your needs.
This includes carbon, alloys and even custom steel grades; annealed, normalized and tempered; stress relieved and stress free; quenched and tempered.
Machinery and automotive seamless steel pipes for automobile skeleton and rear axle pipes, manufacturing and processing of precision equipment and instruments.
Application:
Backbone of Automobile and rear axle tube
Manufacturing and processing of precision equipments, instruments and apparatus
Delivery Condition: GBK, BKS, BK, BKW, NBK
Inspection and Test:
Chemical Composition, Mechanical Properties, Visual and Dimension Test, NDT, Grain Size Test
Surface Treatment:
Oil-dip, Varnish, Shot Blasting
|
Grade |
C |
Mn |
P≤ |
S≤ |
Si |
Cr |
Mo |
| 1010 | 0.08-0.13 | 0.30-0.60 | 0.04 | 0.05 | - | - | - |
| 1020 | 0.18-0.23 | 0.30-0.60 | 0.04 | 0.05 | - | - | - |
| 1045 | 0.43-0.50 | 0.60-0.90 | 0.04 | 0.05 | - | - | - |
| 4130 | 0.28-0.33 | 0.40-0.60 | 0.04 | 0.05 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
| 4140 | 0.38-0.43 | 0.75-1.00 | 0.04 | 0.05 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
|
Grade |
Condition |
Tensile strength |
Yield stength |
Elongation |
|
|
|
Mpa(min) |
Mpa(min) |
%(min) |
| 1020 | CW | 414 | 483 | 5 |
| SR | 345 | 448 | 10 | |
| A | 193 | 331 | 30 | |
| N | 234 | 379 | 22 | |
| 1025 | CW | 448 | 517 | 5 |
| SR | 379 | 483 | 8 | |
| A | 207 | 365 | 25 | |
| N | 248 | 379 | 22 | |
| 4130 | SR | 586 | 724 | 10 |
| A | 379 | 517 | 30 | |
| N | 414 | 621 | 20 | |
| 4140 | SR | 689 | 855 | 10 |
| A | 414 | 552 | 25 | |
| N | 621 | 855 | 20 |
Minimum Quantities
Hot-finished carbon and alloy—10,000 pounds, or 4,536 kilograms minimum.
Cold-drawn carbon and alloy—5,000 pounds minimum or 125 feet minimum, 2,268 kilograms minimum or 38.1 meters minimum, whichever is greater.
Quantity variation—standard ±10% of the ordered weight, or ±25 feet or 7.61 meters, whichever is greater.
Special Configurations
Tubular Products special seamless tubing configurations start with the highest quality steels. Grade, chemical analysis and surface condition are carefully considered, and production processes are tailored to achieve the best tubing for the end use.
The configurations are formed from round tube by cold drawing. The tube is drawn over a shaped mandrel or through a shaped die, or both. Improved tolerances, finishes and mechanical properties result.
Seamless and welded tubes for mechanical and general engineering applications. Tubes for construction and structural purposes such as civil structures, foundations, etc.
|
Standard |
Steel Grade |
|
| EN | 10297 | E355 |
| 10210-1/2 | S235JRH, S275JOH, S275J2H, S355JOH, S355J2H | |
| 10219-1/2 | ||
| DIN | 1629/2448 | St-52 |
| ASTM | A500 | Gr. A, Gr. B |
| A501 | ||
| A618 | Gr. I, Gr. II, Gr. III | |
|
Supply Conditions |
Steel Tubes Provided according to Outside Diameter and Wall Thickness |
Steel Pipes Provided according to Outside Diameter, Inside Diameter and Wall Thickness |
Steel Tubes with the Outside Diameter of 77 mm, Inside Diameter of 57 mm and the Wall Thickness of 10 mm |
||||
|
Allowable Deviation of Diameter and Wall Thickness |
Size (mm) |
Allowable Deviation (%) |
Size |
Allowable Deviation |
Size |
Allowable Deviation |
|
|
Outside Diameter |
±1.0 |
Outside Diameter |
±1.0% |
Outside Diameter |
+1.0 mm-0.55 mm |
||
|
Wall Thickness |
≤ 7 |
6 |
|||||
|
﹥7-15 |
2.5 |
Inside Diameter |
±1.75% |
Inside Diameter |
+1.5 mm-0.5 mm |
||
|
﹥15 |
5 |
Wall-Thickness-Difference |
≤ 15% of Nominal Wall Thickness |
Wall-Thickness-Difference |
≤ 15% of Nominal Wall Thickness |
||
